Nomia 12V340Ah — LiFePO4 Battery
High-capacity lithium battery engineered for demanding marine and industrial power systems. Robust build, smart protection and strong continuous/pulse discharge capabilities.
12.8V nominal
340Ah / 4352Wh
>4000 cycles (100% DoD)
IP50
Downloads
Gallery
.avif)
Specifications
Electrical
- Nominal capacity: 340Ah
- Energy: 4352 Wh
- Open circuit voltage: 13.2 V
- Self-discharge: <3% per month
- Cycle life: >4000 cycles (at 100% DoD)
- Voltage: 12 V
Charge & Discharge
- Charge method: CCCV
- Charge voltage: 14.4 V
- Max charge current: 300 A
- End of discharge voltage: 10 V
- Continuous discharge current: 300 A
- Pulse discharge current: 900 A (30 s)
Mechanical
- Dimensions (L×W×H): 467 × 193 × 233 mm
- Weight: 33 kg
- Case material: GFRP
- Ingress protection: IP50
- Cell configuration: 2P4S — LiFePO4
Note: For environmental limits and detailed PGMs, see
the datasheet.
