Nomada 12V105Ah — LiFePO₄ Modular Battery

Electrical

• Nominal capacity: 105Ah
• Energy: 1344 Wh
• Open circuit voltage: 13.2V
• Self-discharge: <3% per month
• Cycle life: >3500 cycles (at 100% DoD)
• Voltage: 12V

Charge & Discharge

• Charge method: CCCV
• Charge voltage: 14.3–14.6V
• Max charge current: 105A
• End of discharge voltage: 10V
• Continuous discharge current: 105A
• Pulse discharge current: 315A (30s)

Mechanical

• Dimensions (L×W×H): 437 × 90 × 175 mm
• Weight: 10 kg
• Case material: PC-ABS UL94-V0
• Ingress protection: IP66
• Cell type / chemistry: Prismatic — LiFePO₄

Temperature

• Charge: 0°C to 55°C
• Discharge: −20°C to 55°C
• Storage: −20°C to 45°C

Compliance & General

• Certifications: CE, UKCA, FCC, UN 38.3, DNV, UL 1642 (Cells), UN ECE R10.06, EN/IEC 62619-62620 (ESTRIN)
• EAN-13: 8718531361799
• Battery designation: IFpP/36/130/195/[1P4S]M/−20+55/90
