Gobius c
It measures all kinds of fluids, including petrol, diesel and oil.
Gobius C, stepless measurement, 0-100%, version 3.0
Plug and play installation. No disassembly of the tank is needed. Measures from the top, never risk of leakage. Complete system, everything included; sensor, cable, 3M cleaning wipe and an extra 3M sensor tape. Handles voltage of 12-24 Volts. The sensor is mounted in the same simple way as other Gobius products, but on the top of the tank. Max. tank depth is 2 meters. Can be connected to control systems and analog instruments such as KUS, Wema, VDO, Faria (0-190 Ohm, 240-33 Ohm, 4-20 mA and 0-5 V). In addition, there are two individual on/off alarm outputs to signal when the tank is empty and full. Installation is done from your phone via Bluetooth. The app is available in 10 languages.
Contact Sales →General information
- Suitable for all types of fluids
- Plug and play installation
- Multi-language support
- All settings are done automatically
- Built-in Tank Calculator
- Built-in sea wave motion reduction
- No need for removing the tank
- Reading through plastic tank
- No tank wall thickness limit (plastic)
- Adapted for standard holes in metal tanks, 1 1/4″
- No cleaning inside the tank is needed
- No maintenance
Measurement functions
- Measuring range, 20-2000 mm
- Tank depth: Max 2 meters (78 inches)
- Tank depth: Min 0,2 meters (7,8 inches)
- Measuring interval, 1 second
- Resolution: 1 mm
- Accuracy: +/- 2-3 mm
Tank Geometries
- Rectangular
- Irregular
- Vertical circular
- Horizontal circula
Technical description
- Input voltage, 9-29 V DC
- Connector, female 8 pins
- Two digital outputs (level alarms)
- 4-20 mA (galvanically insulated)
- Outputs, 0-190 & 240-33 Ohm
- Output, 0-5 V
- Sensor LED, shows active/measuring
- Power consumption, 10 mA (12 V)
- Built-in Bluetooth, version 5.0
- Built-in temperature sensor
- Built-in accelerometer
- Built-in micro radar sensor
- Max voltage: 29 V
- Max current: 500 mA
- Bluetooth turn on/off
Sensor Facts
- Weight, 65 gram
- Dimensions, high 65 mm, width 95 mm
- Sensor height incl adapter metal tank, 75 mm
- Cable length, 1 m
- Connector on the sensor
- Sensor material, ABS
- Color, orange
- Bluetooth, version 5.0
- Water proof (IP 56)
Software
- App for iOS and Android phones
-
Multi-language support, Chinese, Danish, English,
Finnish, French, German, Italian, Norwegian, Spanish, and Swedish - Installation / change / removal
- Correct level calculation, incl % and liters
- Bluetooth, version 5.0
- Turn on/off Bluetooth after 10 sec.
- Two digital outputs, four states
- Display on the phone
- Built-in test functions
- Built-in supportfunction
